Product Description

Product Overview

  • It can save time and economically cut plants in larger areas.
  • The attachment has a flail hammer to help the mower push through dense debris.
  • The included PTO drive shaft easily connects to your tractor and the belt drive allows for efficient power transfer.
  • Offset category 1, 3 point knot
  • It is recommended for 25-60HP tractors, capable of covering material up to 1.5in diameter.
  • Front safety chains keep out debris, sealed tapered roller bearings, and have brackets for easy storage when not in use.

Specifications

Engine Power Required 25-60 hp Rotor Shaft Speed 2356 rpm
Working Width 60in Hydraulic Fittings Size G1/2 in
Overall Width 64in Hydraulic Hoses Quantity 4
Min. Blade Ground Clearance 0.6in Drive Type Belt Drive
Max. Cutting Diameter

Depends OThe Type OGrass

Spline End 1.375in  Z6
Offset Distance from The Center (Maximum) 77in Driveline Shaft Length T6-LF-63  With Shear Bolt ;
63in-77in [05B-1600]
Tilt-Up Angle 90° PTO Shaft Speed 540 rpm
Tilt-Down Angle 60° 3-Point Hitch CAT 1
Number Of Blades 24 Deck Thickness 0.16in
Blade Type Hammer Side Plate Thickness 0.25in
Size of Blades 3.5 x 3.2 x 1.6in Number of Belts 3
Blade Weight 0.9 lbs Belt Size V Belt 17x991
Blade (Tines)Material Cast Steel Gearbox 0il Type 85W-90
Rotor Bearing SKF Bearing Dimensions (L x W x H) 64 x 27.5 x 28in
Rotor Diameter 4.3in Finsh  Powder Coating
Blade Swing Diameter 14in Warranty 1 Year
Rotor Thickness 0.3in Weight (N.W./G.W.) 657/772 lbs

WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s)  for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
